This guide explains the plot and building plan approval process for homeowners in Lahore. It is recommended to go through the LDA map approval process to avoid unplanned changes and delays and ensure adherence to the guidelines.
The LDA map approval process involves getting approval for a proposed building plan before starting construction, subject to applicable regulations and any additional permissions required for the property.
A basic roadmap:
Plot verification → Architect → Building drawings → Documents and NOCs → Application → Fee payment → LDA review → Corrections, if needed → Approval → Construction → Completion of documentation.
Additional documents, NOCs, or requirements may apply based on the plot type, scheme, and applicable building laws. Approval is not always granted with the submission of an application.
What is LDA Map Approval?
LDA Map Approval is the Lahore Development Authority's (LDA) review of a building plan to approve or disapprove it based on compliance with building and zoning requirements. Before approving a building plan, LDA reviews the design and layout in detail to assess covered area, setbacks, building lines, height, parking, ventilation, open spaces, etc., and to ensure compliance with building and zoning regulations. This enables owners to get an approved building plan before starting construction.
Homeowners should check LDA building regulations that may be available on the LDA website or in the Building and Zoning Regulations 2019 or other amendments, if any.
Step 1: Check your Plot and Ownership Documents
Check that your plot is legally approved before designing your house. Missing documents or plot ownership issues can delay the application process.
Check the following:
Ownership: Keep the transfer letter, ownership certificate, and CNIC.
Possession: Have the required possession documents.
Housing scheme: Check the status of your approval and the society NOC requirements.
Plot history: Check the history of previous constructions and subdivisions.
Relevant authority: LDA or some other authority.
Additional documents required for an approved private housing scheme may include site plans and a society NOC.
Practical tip: Always verify your plot's legal status and construction limits before finalizing your house design to avoid last-minute changes and approval delays.
Step 2: Hire an Architect Familiar with LDA Approvals
Choosing the right architect for LDA approval can help you avoid repeated revisions. The architect must be familiar with building setbacks, covered areas and height limits, parking and building lines, adequate ventilation and basement provisions, floor layouts, and the submission procedures and requirements.
-
Here are questions that can help evaluate this knowledge.
-
Have you recently done LDA residential approvals?
-
Will you do Forms A and B and all the drawings?
-
Does your fee include submission and revisions?
-
Will you do the structural drawings?
-
What will be your professional fees, and what are the official authority fees and housing society charges?
-
Will you send us the final approved drawings?
Confirm the scope, fees, and what will be delivered before making final payment.
Step 3: Prepare a Compliant Building Plan
The architect prepares an LDA building plan based on the plot documents and the project's applicable requirements. The plan may include:
-
Site plan and floor plans (First, second, third, etc. floor plans and basement), if any.
-
Roof plan, elevations, and sections.
-
Staircase and parking arrangements.
-
Open and set-back areas, including light and ventilation.
-
Service ducts, risers, shafts, and other layouts.
Understand Building Rules Before Finalizing the Design
Before finalizing the design, understand the LDA's applicable construction regulations. These may include covered area, setbacks, building heights, parking, basements, boundary walls, and building lines. These depend on the location, plot size, type of construction, and the approval authority's controls.
Verify these with your architect before finalizing the design. You may face difficulties if you design a building based on an already approved house plan. Complying with the above-mentioned requirements is the responsibility of the designer and plan preparer. The plan should reach the scrutiny stage in compliance.
Step 4: Gather the Necessary Documents
Completing LDA map approval documents gives you the best chance of avoiding delays. LDA's published residential checklist identifies some common requirements, but the final checklists can differ from case to case.
Residential documents required may include, but are not limited to:
-
CNIC (copy)
-
Title/transfer documents
-
Possession document
-
Site plan and building plans
-
Forms A and B
-
NOC of Society, if applicable
-
Affidavits/Undertakings
-
Basement Affidavit, if applicable
-
Mortgage-release letter, if required
-
Subdivision approval letter, if applicable
-
Fee challan and payment
-
Digital/scanned copies, if needed
Note: LDA's published checklist includes these document categories and may require other documents in other cases. It is safe to assume that not every homeowner will need to submit the same set of documents. Contact the LDA or the concerned department to verify.
Step 5: Submit the Application Through the Applicable Channel
Once your documents and plans are ready, submit your application through the prescribed channel for your property and application type. Submit the required forms, drawings, documents, and the prescribed fee. The application process is lengthy, so keep the application reference number to follow up on your application status.
For LDA map approval in Lahore, keep a set of the submitted documents, approved payment records, and the drawings. The status of your application can also be checked on the LDA’s official One Window application-status facility.
Step 6: Pay the Applicable Approval Fees
The total cost for building plan approval in Lahore may include fees for an architect, LDA processing charges, society fees, NOC charges, and other government charges. It is advised to request a written breakdown to separate professional services (architect fees) from government fees. An older 2022 LDA schedule stated a residential processing charge of Rupees 10,000; however, this amount may have changed, and the current amount should be checked on the latest official schedule and challan. It is always advised to keep proof of payment and the paid challan, and avoid relying on outdated online information and verbal estimates.
Step 7: Understand What Happens During LDA Review
When an application is submitted, an official review of the application and supporting documents is undertaken by the competent authority. The outcome of the review may be one of the following:
Approved: The application and submission are found in order, and appropriate sanction is accorded to the submitted plan.
Objection/revision required: The reviewer notes that some documents/information are incomplete/unclear, there is a design issue/problem, or another irregularity needs to be corrected/addressed.
Rejected: The application is not approved in the current state due to some issue as stipulated in the applicable rules.
An objection does not mean that the project cannot move further. Often, an objection may be raised over an incomplete/unclear design or documentation issue, which, when resolved, may remove the objection to the reviewer's satisfaction.
How Would LDA Address an Objection?
A clear course of action should be followed, rather than assuming what changes are required:
Request, and then carefully review, the LDA’s written objection or official reason for the request.
Ask the architect to explain the issue in plain language.
Identify the drawing or document that describes the issue.
-
Revise the plans or supporting documents to address the concern.
-
Provide the revised plans or documents through the proper procedures.
-
Retain all submitted plans or documents and the correspondence relating to the submission.
Have your architect make the required revisions and resubmit them through the approved process. The same applies to informally approaching the LDA to explain your position. An application may be rejected. Check the current provisions to confirm your appeal options and when they must be filed. A published version of the LDA’s regulations provided a 30-day appeal period in the case described; however, you should consult the currently in-force provisions to rely on that time period.
How Long Does LDA Map Approval Take?
The time required for LDA map approval depends on the completeness of the documents, design compliance, the size of the building, the status of the plot, the society's requirements, and the workload of the application process. Applications with design errors or missing documents take longer to approve, as the case is sent back for corrections.
Therefore, it is advisable to ask your architect for an estimated timeline, based on similar cases, before submitting the application. You can also check your application status on the LDA official website. This helps you track the current application status.
Can You Start Construction Before Map Approval?
Homeowners should not think they can begin construction simply because they have submitted a map. The drawings and plans approved by the local authority require you to meet all pre-construction requirements. An LDA-approved house plan authorizes construction only according to the sanctioned design, not unapproved changes. It is your responsibility to appoint the right person to do the right job, obtain the appropriate approval, and make all necessary changes to plans and drawings where required. Check with the Local Authority (LA) regarding the type of approved plans required for building permits. Requirements vary by LA.
LDA Map Approval vs. Completion Certificate
Map Approval and Completion Certificate serve different purposes. Map Approval authorizes the proposed building plan and establishes the design to be followed. A Completion Certificate relates to the finished building and confirms compliance with applicable provisions.
An application for a completion certificate is made after construction. It is generally accompanied by ownership records, the applicant’s CNIC, and an original electricity or Sui Gas bill. Keep your sanctioned plans, payment receipts, and inspection records during construction. Confirm the completion-certificate requirements with LDA before applying.
A Homeowner's LDA Approval Checklist
This LDA approval checklist is to be used in the organization of documents and tracking of the building plan approval process in the Lahore Development Authority (LDA). Building plan approval requirements may vary by plot type, housing scheme, and type of construction. Verify the requirements as appropriate before filing the application.
Before Design
- Ensure ownership of the plot
- Confirm possession
- Identify and check requirements of scheme and NOC
- Identify and check LDA rules applicable
Before Submission
-
Engage services of an architect
-
Finalize design
-
Prepare Forms A and B
-
Identify and obtain NOCs and affidavits
-
Finalize building plan drawings
-
Scan documents
During Approval
-
Submit application and pay fees
-
Obtain and keep the reference number
-
Track status of application
-
Reply to objections and correction requests
Before Construction
-
Obtain the required approval or sanction
-
Share the approved drawings with the contractor
-
Ensure the contractor follows the approved drawings and structural design
-
Do not make any major changes to the approved plan
After Construction
-
Verify requirements for completion of a project
-
Maintain approved plans and other completion documents
Conclusion
The LDA map approval process can be less cumbersome for homeowners if they confirm the plot, prepare plans as per LDA requirements, produce the required documents, and follow the stipulated submission and review process. Verifying requirements and fees on time helps avoid delays and costly redesigns.
Always check the latest development regulations, approval and submission process, required documents, and fee schedule before construction via the LDA's official resources. The most important approval to construct is the one stipulated by the LDA. Constructing a house according to an approved plan is the best safeguard for a homeowner's investment. This will help ensure a smooth transition from a proposed house design to construction.
